GEKA GKDRILL60 DRILLING & MILLING line. (Sections)

GKDRILL – VERTICAL DRILLING AND MILLING MACHINES Available in 2m, 4m, 6m and 8m lengths. GKDRILL, includes as standard: > Tool changer for 10 tools SK 40. > Drive motor 7,5 kW. > Variable speed adjustment 140-3800 rpm. > Automatic tool change with auto tool length measuring. > Coolant system. > Pneumatic tool clamping. > Touchscreen 21,5" with CNC Windows 10 OS. > Remote control for manual movement of the axes. > Movable Drill protection. > Additional office license. MACHINE CHARACTERISTICS • Drill head speed range 140-2000 rpm • Y + Z + X axis drive: servo motor • Fast moving X axis: 24 m/min • Y Axis Travel: 580 mm • Rapid feed Y + Z axis: 7.5 m / min • Distance upper edge of the table - lower edge tool holder 700 mm. • Table width: 560 mm • M12 T-slots • SK 40 tool holder • Drilling Ø: 3 – 40 mm • Thread: M4 – M30 • X axis tolerance: +/- 0.1 mm • Y and Z axis tolerance: +/- 0.06 mm • Drive motor drilling head: 7.5 kW • Control: FAGOR 21'' touch screen • Front light curtain • Rear access protection, customer supplied. • LAIP quick change chuck • Machine weight: 6,000 kg CONTROL • Operation via a simple, separate, network-enabled industrial control with an inch touchscreen. • FAGOR CNC environment with embedded Windows 10 OS. • Program memory for parts. • Remote maintenance. • Data import. • Tool memory for drilling tools, with dimensions, speed and feeds. CONTROL & PROGRAMMING GEKADRILL • Simple graphical user interface. • Easiest programming and operation. • You can produce after just one hour of teaching. • No CNC knowledge required!
