Manarola 20 Ton Hydraulic Bush & Bearing Removal T

For removing and instaling bushings and bearings 17-tan pull type hydraulic cylinder provides effort- and time-saving removing and installing works Includes 4 spindles M10 xP1.5, M12 xP178, M14 x P2.0 and M16 x P20 Sleeve sizes: 18-60 mm(ID) and 26-68 mm (OD) with 2 mm increments 48PCS Specification: Hydraulic Cylinder 20 Ton Hydraulic tube adapter Male Connector for ram M10 x P1.50 Spindle, Sliding Nut & Fixing Nut M12 x P1.75 Spindle, Sliding Nut & Fixing Nut M14 x P2.00 Spindle, Sliding Nut & Fixing Nut M16 x P2.00 Spindle, Sliding Nut & Fixing Nut Short Socket 40 mm in Length ( 21 Piece ) Long Socket 110 mm in Length ( 21 Piece ) Socket Sizes OD x ID mm Φ26 x 18mm, Φ28 x 20 mm, Φ30 x 22 mm Φ32 x 24mm, Φ34 x 26 mm, Φ36 x 28 mm Φ38 x 30mm, Φ40 x 32 mm, Φ42 x 34 mm Φ44 x 36mm, Φ46 x 38 mm, Φ48 x 40 mm Φ50 x 42mm, Φ52 x 44 mm, Φ54 x 46 mm Φ56 x 48mm, Φ58 x 50 mm, Φ60 x 52 mm Φ62 x 54mm, Φ64 x 56 mm, Φ66 x 58 mm Φ68 x 60mm When removing an old bushing from a control arm, installing a new bushing into a control arm two sockets are required. One acts as a pushing socket and the other as a recieving socket. The outer diameter of the pushing socket should be 2 mm smaller than the bushing. The inner diameter of the recieving socket should be 2 mm larger than the bushing. Product link : https://irishtoolsshop.com/product/hydraulic-steering-system-pull-tool-set/ Whatsapp : +353877572993 Website : https://irishtoolsshop.com/
